Powerbox Radio System ATOM (handheld version)

Powerbox Radio System ATOM (handheld version)

$1,875.00 USD
$1,875.00 USD
Sale Sold out
Shipping calculated at checkout.

Powerbox Radio System ATOM (handheld version)

Description

PowerBox ATOM - The best technology in a more affordable package!

Rolling in!

Our ATOM radio control system establishes a new standard in the market segment of upper mid-range systems. Based on the considerable expertise we have gained from the CORE, together with new developments in electronics, revised software, a smaller Linux computer and a revision to the method of case manufacture, we have been able to create a system which has few rivals in terms of price : performance ratio.
The system’s crucial feature is the ingeniously simple operating system, which is exactly the same as that of the CORE - it is even possible to interchange model files between the ATOM* and CORE.
As you would expect from PowerBox, we have allowed no compromises in the matter of redundancy: the radio system and its power supply are of fully redundant design.

Find out more on our Corporate Website

Features
  • 18-channel radio control system:
  • Full 2048-step resolution for all 18 channels
  • Genuinely redundant 2.4GHz transmission for extreme resistance to interference
  • Extreme range
  • Redundant PowerBox power supply system with Li-Ion batteries
  • Powerful real-time telemetry
  • Up to 800 telemetry values per second
  • Open servo and telemetry bus interface
  • Sensors and receivers can be set up conveniently from the transmitter
  • Ability to bind two receivers with equal rights
  • Same speed of telemetry and reception with both receivers
  • Robust stick units machined from solid aluminum
  • Quadruple ball races
  • Hall sensors for sticks and linear controls
  • 20 transmitter controls + 2 optional stick switches
Technical Data
Power supply Li-Ion
Channels 18
Servo signal resolution 2048 Bit
Screen TFT - Touch
Weight 1190g
Temperature range -30°C to +85°C
Set contents
  • PowerBox Atom
  • 1x PBR-9D
  • Case
  • Padded transmitter strap
  • Mains PSU
  • Conversion tool
Documents

FCC Grant 2ASCM-PBXCORE

ISED Certificate 24594-PBXCORE
